fa7-6e series dustproof and waterproof push-button switches

产品描述product description

fa7-6e series are special type push-button switch, commonly for used in home appliances or gardening tools such as vacuum cleaners, chargeable lights, table lights, grass trimmers, etc.


◆可选带以下功能 optional with following function:
→单极常开 spno
→单极常开带自锁 spno with latching
optional with protection cap for dustproof and waterproof (after installed with the appliances)

技术数据technical data

→机械耐久寿命 mechanical life endurance≥1e5
→电气耐久寿命 electrical life endurance≥5e4
→最大冲击电流 max. inrush current at 250v48a
→接触电阻 contact resistance≤30m ohm
→绝缘电阻 insulation resistance≥7m ohm
→基本介电强度 die lectric strength of function1500v
→加强介电强度 dielectric strength of reinforced3000v
→环境温度 ambient temperature0°c~85°c
→操动件温度 actuator temperature0°c~55°c
→阻燃等级 flammabilityul 94v-0
→防护等级 protection typeip40
→适用于ii类防护器具 suitable for appliances of protection class ii


◆输入端/输出端 input side/output side:
→插片端子 plug-in terminals 4.8×0.8mm
→插片端子 plug-in terminals 4.8×0.6mm
→焊接端子 soldering terminals
→线路板焊接端子 pcb soldering terminals

电气参数和认证 electric rating and certification

订货信息ordering information
