fr-6e交流转盘调速器

fr-6e series ac dial wheel speed controls

产品描述product description

fr-6e系列是一款通用型的转盘电子调速器,集成一般防尘功能,应用于各类手持电动工具,如:电锤、曲线锯、往复锯、抛光机、搅拌器、电木铣、砂光机、100、125和150角向磨光机、模具电磨等。

fr-6e series are one general type ac dial wheel speed controls, integrated dustproof, for popular used in portable power-tools such as: rotary hammers, jig saws, reciprocating saws, polisher grinders, electric mixers, electric routers,sanders, 100~150mm angle grinders, die grinders, etc.

产品特征features

◆可选带以下功能 optional with following function:
→全波调速 full-wave speed control
→半波调速 half-wave speed control
→on-off通断功能带可变电阻输出 on-off version with passive linear potentiometer
→带可变电阻输出 with passive linear potentiometer
◆可选带以下附件 optional with the accessories as follows:
→初始电压微调节旋钮 knob for adjusting start voltage
→可控硅外置适合更大电流并可附带散热片
external triac version for high currents additional with heat sink
▲可选转盘一档印字与壳体上表面成67.5°
▲optional the angle between the printing of 1 and the up surface of shell is 67.5
■可选转盘一档印字与壳体上表面成90°
■optional the angle between the printing of 1 and the up surface of shellis 90°

技术数据technical data

→机械耐久寿命 mechanical life endurance≥1e5
→电气耐久寿命 electrical life endurance≥5e4
→最大电流 max. current at 250v10a
→最大电流 max. current at 125v16a
→接触电阻 contact resistance≤30m ohm
→绝缘电阻 insulation resistance≥7m ohm
→基本介电强度 dielectric strength of function500v
→加强介电强度 dielectric strength of reinforced3000v
→环境温度 ambient temperature0°c~55°c
→阻燃等级 flammabilityul 94v-0
→防护等级 protection typeip40
→开关内部电子部分在相应使用中一并做过相关测试,本开关适合做二类器具开关使用.
→the electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class ii.

端子类型terminals

◆输入端/输出端 input side/output side:

→插入式端子可插入沾锡导线、带插片端子导线或铜包头导线

→push-in terminals for soldered strands, strands with end sleeves or strands with end claws

电气参数和认证 electric rating and certification

订货信息ordering information
